Technical Details

  • Display / Monitor



    Modern displays with IPS panels have bright areas along the frame as a normal characteristic. This has hardly any influence on everyday operation, not least because the displays are optimized for daylight operation. It can only be minimized, but not completely avoided, regardless of the manufacturer and for manufacturing reasons. Details on pixel error classes can be found here.

    15.6” Full HD IPS | 60 Hz

    • Type: LED-Backlight display, matte / non-glare
    • Viewing angles: 89°/89°/89°/89°
    • Refresh rate: 60 Hz
    • Resolution: 1920 x 1080 pixels
    • Color gamut: ~90 % sRGB
    • Brightness: ~300 nits
    • Contrast: ~800:1
    • Display model: AUO B156HAN02.0
  • Chassis

    Materials:

    Display lid and bottom panel made of aluminum. Display frame and base unit are made of plastic.

    Dimensions:

    • Width: 360 mm; Height: 20 mm; Depth: 239 mm.
    • Weight: 1.75 kg incl. battery.
  • Keyboard and Touchpad



    • Multi-color (15 colors) backlit keyboard, means that the writing on the keys have backlight! Brightness can be controlled and deactivated by special keys.
    •  COM super-key on all layouts!
    •  Big 121 x 73 mm precision clickpad with integrated buttons and multi-gesture- & scroll-function.
  • Battery & power supply

    49 Wh battery, Lithium polymer
    Replaceable (internally screwed and fixed by tape, but easy to detach)

    Power supply: 45 Watts (95 x 40 x 27 mm | 270 g incl. power cord)
    Power plug:
    Type: Coaxial
    Inner diameter: 1.7 mm
    Outer diameter: 4.75 mm
    Length: 11 mm

    Power can also be supplied via USB-C. Requirement: 20V, min. 3.25A (65 Watts)

    Battery life:
    About 9-10 hours at min. display-brightness, without Wifi & Bluetooth, without keyboard backlit, in idle mode.
    About 5-6 hours at medium brightness with Wifi, at office work and videostreaming.

    Shipping Mode (mode for minimizing battery discharge in the off state)

  • Main processor



    Intel Core i5-1235U
    10 cores (8 Efficient-cores | 2 Performance-cores) | 12 Threads | Max. 4.4 GHz | 12 MB L3-Cache, 15 Watts TDP

  • Graphics card

    Intel Iris Xe Graphics | Integrated CPU graphics.

    EUs (Execution Units): 80 | Graphics clock rate: 1.2 GHz.

    It is possible to drive 4 displays at the same time. 3 external plus the internal notebook display or 4 external displays. For connecting more than one monitor via DisplayPort 1.4 (USB-C), we recommend using an USB-C-to-DisplayPort MST hub.

    Max. resolution (HDMI 2.0): 3840 x 2160 @ 30 Hz or 1920 x 1080 @ 120 Hz
    Max. resolution (DisplayPort 1.4a): 7680 x 4320 @ 60 Hz or 2x 3840 x 2160 @ 60 Hz

  • Memory



    DDR4 3200 MHz SoDIMM | 2 sockets | replaceable | Max. 64 GB | Dual Channel

  • Mass storage (SSD / HDD)



    1x M.2 2280 für NVME SSD (PCIe Gen4x4)
    Intel Optane Technology

  • Communication / Network



    Wired/LAN:
    10/100/1000Mb LAN.

    Wireless/WIFI:

      • Intel Wi-Fi 6E AX211:
      • Interface: M.2 2230 / CNVio2
      • Wireless LAN / WLAN standards: 802.11 ac/a/b/g/n/ax
      • DualBand 2,4 / 5 / 6 GHz
      • Communication channels: 2×2
      • Transfer rate: 300 Mbit/s (2.4GHz WIFI) / 2,4Gbps (5GHz WIFI).

    Bluetooth:
    Integrated in above Intel Dual Band Wi-Fi 6E AX211
    Version: Dual Mode Bluetooth 5.2

  • Webcam / Laptop camera

    2.0 Megapixel (1920 x 1080 pixels) webcam

  • Sound / Audio



    High Definition Audio
    2 x integrated speakers
    Integrated microphone

  • Ports



    Left side (from left to right):

    • Kensington Lock
    • RJ45 Port (LAN)
    • microSD card reader
    • USB-A 3.2 Gen1
    • USB-A 2.0
    • LTE sim card slot (format: Mini SIM (2FF))
    • 2-in-1 audio jack (headphone out + microphone in)

    Right side (from left to right):

    • Thunderbolt 4 / USB-C 4 Gen3x1 (Hardwired to: iGPU | NO DisplayPort 1.4a | NO PowerDelivery DC-In | DC-Out: max. 15 Watt (5 V / 3 A))

    Back side (from left to right):

    • USB-C 3.2 Gen2×1 (Connected to: iGPU | DisplayPort 1.4a | Power Delivery DC-In* | DC-Out: max. 15 Watts (5 V / 3 A))
    • USB-A 3.2 Gen2
    • HDMI 1.4b (with HDCP)
    • Power plug (DC-In)
  • Card reader



    microSD card reader

  • Security



    • Kensington-Lock mounting
    • Webcam & audio can be deactivated directly via the UEFI / BIOS
    • Wifi & Bluetooth can be deactivated directly via the UEFI / BIOS
    • TPM 2.0
  • Cooling System & Fan



    Temperature controlled fan
    At low system workload, there is less heat emerging. The cooling system fans can spin accordingly slow or even turn themselves off completely. Depending on the chassis, cooling system and CPU and GPU, high to very high fan noise (air swooshing) is produced under full load. Thinner notebooks normally tend to get louder due to less cooling capacity.

System Service

  • Operating systems



    We install Ubuntu and BlueOS (based on Ubuntu with KDE Plasma Desktop) in the latest 64-bit version with long term support.

    With our fully automatic installation WebFAI you can easily perform a Linux installation exactly as we at Commodore do it in our production! You can choose from all distributions that we also offer in our configurator. Depending on the distribution, you have the choice between different desktop interfaces.


    Encrypted Installation

    On request, we install your Linux system completely encrypted. The pre-installation as dual boot with Windows is technically not possible.
    Further details as well as a detailed introduction to encryption can be found here.

    Windows on request

    If you don’t want or can’t do without Windows, we install the desired Windows version next to Linux or alone. Please understand that a dual-boot installation can take 1-2 working days longer, even though the process is fully automatic. Please also note that we provide you with a correct Windows license incl. license sticker and installation DVD!

    Windows Drivers

    The corresponding Windows drivers are already included as standard with every device, regardless of whether it is with or without Windows or operating system installation. Alternatively, you are free to download all Windows-Drivers from here.

  • UEFI firmware

    With all our notebooks, you have the possibility to protect your privacy already on firmware level using the UEFI (Unified Extensible Firmware Interface).

    For this purpose, the following functions can be completely deactivated:

    • On Intel CPUs: Intel Management Engine (IntelME)
    • Webcam
    • On Intel CPUs: Audio (Microphone & Sound)
    • WLAN & Bluetooth

    In addition, our Premium UEFI firmware allows chipset-specific settings and definitions for hardware components in order to run adjust the device optimally to your use case.

    Please note: All notebooks built in 2021 and later do not support switching the UEFI firmware to the outdated BIOS firmware standard.

  • Warranty



    2 years pick up and return (12 months on wearing parts like battery & power supply)

    Optional: Up to 5 years pick up and return (12 months on wearing parts like battery & power supply)

    All devices have a maintenance-friendly design. Depending on the model, the essential hardware components such as processor, drive, hard disks, RAM, WIFI modules etc. can be accessed via maintenance flaps or removable floor trays. Furthermore the battery is replaceable if not stated differently. Of course, even after expiration of your warranty period, we’re offering replacement parts and service for many years!

    For warranty cases, we’ll provide you with a free return label after getting in touch with us. Warranty handling is done via our technical support.

  • Package Contents



    • 1x Commodore Vega-Book preinstalled & configured
    • 1x Power supply
    • 1x Power cord
    • 1x Recharchable battery
    • 1x First steps manual incl. short technical manual
    • 1x WebFAI USB drive (www.webfai.de) for Linux recovery
    • 1x Drivers for Windows downloadable
    • 1x For the installation of own SSDs or HDDs necessary screws
    • 1x Commodore Computers fan package consisting of two posters, two pens and additional, seasonal goodies 🙂

Vega-book

 896,00 VAT included

Out of stock
