CONFIGURE YOUR COMMODORE LAPTOP
Choose product options and continue
The new Omnia-book
€ 1.596,00 VAT included
Technical Details
-
Display / Monitor
Modern displays with IPS panels have bright areas along the frame as a normal characteristic. This has hardly any influence on everyday operation, not least because the displays are optimized for daylight operation. It can only be minimized, but not completely avoided, regardless of the manufacturer and for manufacturing reasons.
15.3-inch Omnia display
- Screen size: 15.3″, 16:10
- Type: LED-Backlight Display, matte/non-glare
- Viewing angles: 89°/89°/89°/89°
- Refresh rates: 60 Hz, 240 Hz
- Resolution: 2560 x 1600 Pixels
- Color gamut: 100 % sRGB
- Brightness: ~500 nits
- Contrast: ~1000:1
- Additional features: G-Sync
- Display model: BOE NE153QDM-NZ1
- Opening angle: ~ 180°
-
Chassis
Materials:
-
- Display lid, base unit and bottom case made of aluminum
- Display frame made of plastics
Dimensions:
- width: 34.2 cm; height: 2 cm; depth: 23.8 cm
- Weight: 1.6 kg with battery
Maintenance: After removing a series of screws from the bottom panel, RAM, Wi-Fi card, SSDs and fans are easily accessible, easy to maintain, clean and replace.
-
-
Keyboard and Touchpad
Mechanical keyboard with number pad.
Quiet rubberdome / membrane keyboard with 4-row number pad and full-size arrow keys.
White keyboard backlight Brightness can be controlled and deactivated by special keys.
COM super-key on all layouts.Glass precision clickpad (121 x 73 mm) with integrated buttons and multi-gesture- & scroll-function
-
Battery & power supply
Maximally large 99 Wh battery, Lithium polymer (screwed inside)
Power supply:
- 100 WW | 20 V / 5 A | USB-C Power Delivery DC-In | 124 x 64 x 29 mm | 350 g incl. cable
Battery life:
up to 15 hours at min. display-brightness, without Wifi & Bluetooth, without keyboard backlit, in idle mode.
up to 10 hours at medium brightness (~ 150 nits), without Wifi & Bluetooth, without keyboard backlight, in local video playback.
up to 8 hours at medium brightness with Wifi, at office work.* Maximum sustained performance at full fan speed.
-
Main processor
Intel Core Ultra 7 155H
(16 Cores (6 Performance cores | 4 Efficient cores | 2 Low Power Efficient cores) | 22 Threads | Max. 4,8 GHz | 24 MB L3-Cache, 60 W*)
* Maximum sustained performance at full fan speed.
-
Graphics card
Energy efficient CPU integrated Graphics:
Intel Arc graphics
It is possible to drive 4 displays at the same time (3x external screens plus the internal notebook display.)
- 1x internal notebook display.
- 1x HDMI 2.1
- 2x USB-C (DisplayPort 1.4).
-
Memory
Type: DDR5-5600 MHz
SO-DIMM | 2 sockets upgradeable | max. 96 GB (4800 MHz) | Dual Channel -
Mass storage (SSD / HDD)
2x M.2 2280 for NVME (PCI-Express 4.0 x4)
Intel Optane Technology -
Communication / Network
Wired/LAN:
1 Gigabit LAN (Motorcomm YT6801, 10/100/1000 Mbit/s)Wireless/WIFI:
-
- Intel Wi-Fi 6E AX211:
- Interface: M.2 2230 / CNVio2
- Wireless LAN / WLAN standards: 802.11 ac/a/b/g/n/ax
- DualBand 2,4 / 5/6 GHz
- Communication channels: 2×2
- Transfer rate: 300 Mbit/s (2.4GHz WIFI) / 2,4Gbps (5GHz WIFI).
Bluetooth:
Integrated in above Intel Dual Band Wi-Fi 6E AX211
Version: Dual Mode Bluetooth 5.3 -
-
Webcam / Laptop camera
2.0 Megapixel (1920 x 1080 pixels) webcam with camera shutter
-
Sound / Audio
High Definition Audio
2 speakers: 2x 2W
Integrated microphone -
Ports
Left side (from left to right):
- Kensington Lock
- USB-A 2.0
- USB-A 3.2 Gen2 (10 GBit/s | DisplayPort 1.4 | Power Delivery DC-In*)
- 2-in-1 audio (headphone + mic)
Right side (from left to right):
- Card reader (SD/SDHC/SDXC)
- 2x USB-A 3.2 Gen1
Back side (from left to right):
- HDMI 2.1 (HDCP 2.3)
- Thunderbolt 4 (40 GBit/s | DisplayPort 2.1 | Power Delivery DC-In* | DC-Out: max. 15 watts (5 V / 3 A))
- RJ45 Port 1 Gbit (LAN)
- *Requirement: 20V / 5A (100 Watts)
*Requirement: 20V / 5A (100 Watts)
-
Full size SD card reader (SD/SDHC/SDXC)
Speed: 985 MB/s -
Cooling System & Fan
Temperature controlled fan
At low system workload, there is less heat emerging. The cooling system fans can spin accordingly slow or even turn themselves off completely. Depending on the chassis, cooling system and CPU and GPU, high to very high fan noise (air swooshing) is produced under full load. Thinner notebooks normally tend to get louder due to less cooling capacity.Custom performance and fan control with the COMMODORE Control Center
With the COMMODORE Control Center you are able to control the performance and the behavior of the fans by yourself. This means that you get the ability to make your device as quiet as possible. By heavily reducing the performance you are able to set the device almost passive cooled, without any fan noise most of the time!
System Service
-
We install Ubuntu (based on Ubuntu with KDE Plasma Desktop) in the latest 64-bit version with long term support.
With our fully automatic installation WebFAI you can easily perform a Linux installation exactly as we at Commodore do it in our production! You can choose from all distributions that we also offer in our configurator. Depending on the distribution, you have the choice between different desktop interfaces.
Encrypted InstallationOn request, we install your Linux system completely encrypted. The pre-installation as dual boot with Windows is technically not possible.
Further details as well as a detailed introduction to encryption can be found here.Windows on request
If you don’t want or can’t do without Windows, we install the desired Windows version next to Linux or alone. Please understand that a dual-boot installation can take 1-2 working days longer, even though the process is fully automatic. Please also note that we provide you with a correct Windows license incl. license sticker and installation DVD!
Windows Drivers
The corresponding Windows drivers are already included as standard with every device, regardless of whether it is with or without Windows or operating system installation. Alternatively, you are free to download all Windows-Drivers from here.
-
UEFI firmware
With all our notebooks, you have the possibility to protect your privacy already on firmware level using the UEFI (Unified Extensible Firmware Interface).
For this purpose, the following functions can be completely deactivated:
- On Intel CPUs: Intel Management Engine (IntelME)
- Webcam
- On Intel CPUs: Audio (Microphone & Sound)
- WLAN & Bluetooth
In addition, our Premium UEFI firmware allows chipset-specific settings and definitions for hardware components in order to run adjust the device optimally to your use case.
Please note: All notebooks built in 2021 and later do not support switching the UEFI firmware to the outdated BIOS firmware standard.
-
Warranty
2 years pick up and return (12 months on wearing parts like battery & power supply)
Optional: Up to 5 years pick up and return (12 months on wearing parts like battery & power supply)
All devices have a maintenance-friendly design. Depending on the model, the essential hardware components such as processor, drive, hard disks, RAM, WIFI modules etc. can be accessed via maintenance flaps or removable floor trays. Furthermore the battery is replaceable if not stated differently. Of course, even after expiration of your warranty period, we’re offering replacement parts and service for many years!
For warranty cases, we’ll provide you with a free return label after getting in touch with us. Warranty handling is done via our technical support.
-
Package Contents
- 1x Commodore Omnia-Book preinstalled & configured
- 1x Power supply
- 1x Power cord
- 1x Recharchable battery
- 1x First steps manual incl. short technical manual
- 1x Drivers for Windows downloadable
- 1x For the installation of own SSDs or HDDs necessary screws
- 1x Commodore Computers fan package consisting of two posters, two pens and additional, seasonal goodies 🙂
